David Ryan and Howard Samuels

First Impressions

The Naída CI M90 is the first Advanced Bionics processor to be produced entirely under the Sonova umbrella from concept on through production. It has the same appearance as the Phonak Naída M90 hearing aid.

The M90 is slightly smaller and thinner than the previous Q series processors, but is now ergonomically shaped for comfort and positioning. The curved shape of the processor and batteries distributes the weight for greater comfort while also ensuring the processor is positioned for optimal microphone placement.

The M Slim HeadPiece now has a permanently-attached cable. This was the design of the older generation Harmony processor’s headpiece and cable, which in my experience made for a robust design that required changing only once during a 7 year period. The design is much thinner and lays flat against the head compared to the Universal HeadPiece design with a detachable cable of the previous Q series. The strain relief features on both ends of the cable have also changed. They are smaller, and may provide improved reliability. Numbered magnets are inserted by your audiologist for just the right amount of grip. If you need a very high-strength magnet, a color cap about the same thickness as the UHP is available. The new Slim AquaMic is exactly the same size as the Slim Headpiece.

The power-up time is a few seconds with only a short start-up jingle. You can miss the chimes if you don’t place the processor on your head fast enough.

Program change times were previously a common complaint with the Q series.  It took several seconds to change programs. Savvy users learned to cycle through programs without waiting for each program to come up to speed the process up, but still required sitting in silence until the switch was made. Program changes are immediate unless switching between program strategies (i.e. S or P) in which case the cut out is extremely brief. With AutoSense (described below) manual program changes are largely unnecessary.

Microphones

As with the Q series; the M90 has 4 microphones to choose from: the M T-Mic, the BTE Mic, rear-facing mic, and the headpiece mic. What’s changed about the microphones on the Marvel is the headpiece mic is no longer an option on the 3.5” and 4.25” lengths intended for on-ear wear.  A Slim Headpiece with a microphone and a 12″cable length is available for off-ear use.

Longer lengths require the use of the Waterproof Battery, which is ideal for physical activity and water-use to secure the processor to the body. The Waterproof Battery is a small waterproof case that holds the M90 without its T-mic or earhook. It includes a USB-chargeable internal battery. The Aqua Slim HP is a waterproof combination headpiece and waterproof microphone, and comes in lengths of 12”, 18”, 24”, and 42”.

Sound Processing

DR: The M90 is an entirely new processor and system. It has a new sound that is distinctive from the previous Q series. It’s difficult to quantify that difference other than it seems to be more sensitive and offer subtle details that were not there previously both in everyday sounds and music. Adapting to the new sound is effortless and should only offer performance gains.

HS: The sound quality is brighter than with my previous Q70s, even when running the same fixed program.  Subtle environmental sounds, such as the collar of my shirt rubbing against my neck. The additional sounds don’t interfere with my speech comprehension.  If anything, they make me feel more connected to the environment.

Programs are based on “scene classifiers.” AutoSense uses scene classifiers to identify optimal settings for each acoustic environment you are in. They are: Calm Situation, Speech in Noise, Speech in Loud Noise, Speech in Car, Comfort in Noise, Comfort in Echo, and Music. Four of these, Calm Situation, Comfort in Noise, Speech in Noise, and Comfort in Echo, are blended depending on the environment, rather than having only one selected automatically or manually. In addition to these classifiers, SoundRelax and WindBlock are available in varying degrees of strength that can be set by your Audiologist and are enabled by default. To create a custom program, your Audiologist will select from these scenes to best match the desired results. A recipient desiring a program that is non-reactive to any environment (or no features) would choose “Calm Situation” for that custom program. If a manual beam-former program is desired then the Audiologist would go with “Speech in Noise.”

The Music scene classifier applies a higher input limit and wider dynamic range than other scenes. While conversing in a car, music would play quietly underneath speech, but would become louder and clearer when speech stopped. The compression ratio is slower with this scene.  When listening to input over the Bluetooth connection, AutoSense chooses either Media Speech or Media Music, applying similar parameters to optimize the quality of both.  A separate custom program may be set for Music is desired.

AutoSense 3.0 is interwoven into the system.  It is designed to be the only program you will ever need.  Rather than the 5-program structure of the Q series, the M90 offers AutoSense 3.0 plus the option to add up to 4 custom programs.  While AutoSense is intended to be the default program upon start-up, it can be placed at the end of your custom program selections and a custom program may be selected as your default. It’s important to understand this structure to avoid confusion.  AutoSense has a distinctive audible chime that identifies it as the current program.  Any custom programs are identified by the number of chimes, regardless of whether AutoSense is made the default or placed at the end of the custom programs.

AutoSense 3.0 is both the evolution of Auto-UltraZoom as found on the Q90 and is not Auto-UltraZoom at all. It is constantly analyzing your environment and applying changes at rapid fire pace while seamlessly blending the scene classifiers mentioned previously. It all happens without you noticing other than your ability to hear is optimized. In many ways, it is similar to the ClearVoice programming strategy (with which it can be combined), but without the changes in sound quality since it is utilizing front-end features via the microphone.

DR: AutoSense is more of a “challenging environments” program for my use. I can count on it to handle truly loud and challenging environments by focusing on those I need to or cancelling out echo, but it also can overstep in environments I do not consider to be noisy.  For the latter, I retain my custom “no-features, wide open IDR” program as a baseline for my hearing. I no longer have a manual UltraZoom program as AutoSense has replaced the need. This is notable since I have never been one to use auto-programs such as ClearVoice or Auto-UltraZoom.  UltraZoom was the first truly helpful feature for hearing in noise and was the only program I switched to on the Q70. I am able to remain in AutoSense most of the time with it working to be helpful rather than impede my listening, so I’m finally able to enjoy “Auto-UltraZoom” functionality in advanced form.

HS: AutoSense is my default program, and it is doing a great job in the various environments I’ve encountered to date. My prior default program used 100% T-mic for everyday situations.  It’s available in a spare program slot just in case AutoSense doesn’t live up to my expectations. There is one more fixed program – Speech in Loud Noise. So far I haven’t had to switch to either fixed program – AutoSense is doing a great job! I may end up using a fixed program when I’m only listening to music through the microphones.

Bilateral Features

The Q70 has two microphones at the top of the processor. They work together in UltraZoom to focus the sound directly in front of you. This works great in a noisy restaurant.

The Q90 adds StereoZoom for bilateral and bimodal users. It uses mics from both processors, which communicate with each other wirelessly, to do an even better job focusing on the sound in front of you. The greater separation between mics facilitates this advanced capability. Bimodal users can take advantage of this with the Link hearing aid. This is one example of how Advanced Bionics processors and Phonak hearing aids work together. No other cochlear implant and hearing aid combination works like this.

For bimodal users, the Phonak Naida Link M Hearing Aid includes all of the bilateral features when you have one cochlear implant and one hearing aid. It’s available as an option on the M90 order form.

Speech in 360 is a separate custom program that builds on Speech in Loud Noise. It focuses on sounds in front of you.  But if a waiter starts talking to your side, it shifts the focus to that direction!  It is not part of AutoSense, so you have to switch to that program. I plan to replace my custom Speech in Loud Noise program to Speech in 360.  AutoSense does a great job of deciding when to use Speech in Loud Noise, so it isn’t needed as a separate program.

As with the Q70 and Q90, you can change programs or the volume of both devices by pressing a button on either one. If AutoSense continues to perform as well as it has been, there will be no need to press buttons to adjust anything about your hearing.

The Q70 and Q90 are the only cochlear implant processors that can be programmed for both ears.  You can put either processor on either ear, and the correct set of programs will load. This is useful for bilateral users in case one processor has a problem. If you prefer to use one side more than the other, or perform better on one side, you can just put the remaining processor on your best side.  In addition, you can swap sides as part of a debugging process to localize the problem. This capability has been dropped from the M90 processors to make room for the more advanced features.

Wireless Features

The first wireless feature you will encounter is the wireless programming interface at the audiologist’s office! There are no cables from the audiologist’s computer to your processor(s). The audiologist can even program the M90 processor on one ear, and the corresponding Link hearing aid on the other side, both wirelessly, at the same time. All changes the audiologist makes are updated right away. You can hear for the entire programming session. When all settings are finalized, it only takes a few seconds to save them to the processor.

The M90 is the only CI processor with true Bluetooth connectivity to all devices! It even works in true stereo for bilateral and bimodal users. All other CI processors use Made For iPhone and/or ASHA (Android 10 and up) connectivity for hearing aids. Those devices are only able stream from mobile devices with the correct OS. They are also only one-way audio connections – you need to use the mic on the phone to talk, so the phone can’t be in your pocket or purse. Some other CI processors do have full Bluetooth connectivity – but only with an intermediary device that you clip onto your clothing or wear on a neckloop.

The Marvel hearing aids and CI processor connect via Bluetooth as “headphone” or “headset” to all Bluetooth devices with Bluetooth version 2.1 and above.  They even work with many older phones utilizing versions of Bluetooth below 2.1! The M90 can be a complete wireless headset for video calls on any Bluetooth device, including your computer.

The connection strength of the M90’s Bluetooth is excellent and comparable to high-end consumer Bluetooth headphones. There is never a break in the stream, so you can move one or two rooms away from your phone without losing connection. The stream is in true stereo when listening to music or media, and will also stream to both sides on phone calls for bilateral or bimodal users with the Phonak Naída Link M.

Having true Bluetooth on-board the M90 gives you the ability to make hands-free phone calls with the phone in your pocket or purse. You can answer a call or hang up with a press of a button on the processor. Calls are streamed directly to your processor/s with your own voice picked up by the BTE mic. Call clarity is pristine on both ends with your out-going voice sounding as clear to those on the other end as if you were holding the phone up to your mouth. Having had a very social weekend to celebrate my recent birthday, I found myself being the one in the group (everybody else with normal hearing) to make calls to various restaurants to gather information while there was lots of noise on both ends of the conversation.  Not a single word was missed nor was there any struggle at all!  During a call, you can adjust the volume either with the M90 volume buttons or on your phone’s volume rocker.

Up to two devices can be paired and held in memory on the M90. Only one of these devices can be connected to the M90 at a time. When switching between the two devices that are both in range and powered on; you need to first disconnect one (not “forget” or unpair) and then connect the other device (usually done within the Bluetooth settings for that device).  Switching may also happen automatically where the connected device is turned off and the other device then resumes connection. Additional pairings are possible, but if two devices have already been paired, one device will be replaced by the new device. You will need to re-pair the previously paired device to restore it to memory. Presently, my smartphone and my PC are the two paired devices I can switch back and forth from with little fuss.

If your phone is paired to your car audio system and to your M90 processor, phone calls will go to the processor when you are not in the car. The car takes priority, so calls automatically go through the car audio system when you are in the vehicle. If you prefer to use the Bluetooth connection to the M90 instead of the car audio system, don’t pair the phone with the car.

The TV Connector accessory adds further connectivity options into the mix. It utilizes Airstream; Phonak’s proprietary streaming protocol.  This is different from Bluetooth in that multiple users can connect to one TV Connector device to hear in full audio quality stereo sound on demand.  Despite the name, TV Connector can be used with any device outputting sound via either TOSLink/Optical or 3.5 mm analog (ideal for headphone outputs.)  You can plug it into the headphone output jack of a computer as a method to simplify switching between Bluetooth streaming from your phone and the computer.  Airstream is a stereo stream that does not merge into mono for unilateral recipients (Bluetooth will merge as needed.)

Other wireless accessories include the Phonak Roger Select IN, the Phonak PartnerMic, and the Phonak Remote Control.

AB Remote App

•

•

•

The AB Remote app, available for Android and iOS, gives you access to some basic features from your phone. You can check the battery levels, adjust volume (independently or both at once), set surround mix, and change programs from a drop-down list.  In addition, you can check the status of the processor, play a beep, or blink an LED, which is useful for caregivers. The app may be downloaded from the App Store or Play Store and utilized in demo mode for those wishing to check it out in advance.

Batteries

Each of the three rechargeable battery sizes is smaller than the corresponding options for the Q series. A case for disposable Zinc-Air batteries is also available. I got 21 hours of battery life with new 150mAh medium batteries on the M90. With new 170mAh batteries on the Q70, I got about 16 hours. This means the combination of the new processor and software is about 50% more efficient!

Waterproof Battery

The M90 can be put inside the new M Waterproof Battery that essentially turns it into a smaller Neptune (the world’s only fully waterproof CI processor, which has recently been discontinued) with wireless capabilities. The casing has a battery built-in and is charged directly via micro-USB. You could theoretically install a backup processor if you have one, leave the case locked, and use it as a fulltime off-ear processor for physical and water activity. The form factor ensures the processor is protected and secured to your body.  Ocean waves will knock a CI processor right off your head without fail, so if it is not secured it will turn up on a deserted island someday.

I primarily use this during my weight-lifting workouts. I can get drenched with sweat without worry for the processor. The wireless streaming lets me listen to my music playlists to power me through my routine. I’m looking forward to wearing it at amusement parks while riding roller coasters knowing it is secure and enjoying hearing the terrified screams of fellow riders.

Charger

The battery charger is comparable in size to the Q series charger.  However, it only charges three batteries at a time, while the Q charger has four slots. As a bilateral user, I like to have four batteries on the charger overnight. Two go on my processors in the morning, and the other two are carried with me in case the batteries die while I’m out for the day. Now I need to keep two chargers on my nightstand to charge four batteries at once. Update: With 21 hours on a medium battery, you may not worry about a battery dying during the day. You can still carry spares in case of emergency, but they don’t have to be charged every day.

The LEDs are much dimmer than those on the Q series charger. This is a welcome improvement for people who like to sleep in a very dark room.

The charger uses a Micro-USB connection. The supplied cables are pretty stiff. Aftermarket quality flexible cables will make the wire routing for the two chargers as easy as possible.

Dryer

The Cedis dryer supplied with the kit is much smaller than the Zephyr which came with the Q series.  Two M90 processors with headpieces can fit in the compartment without undue flexing of the headpiece cable. The charger uses a mini (not micro) USB connector. While the dryer and battery chargers usually remain plugged in, so you don’t have to fiddle with micro and mini USB connectors on a regular basis, a system where all the accessories use USB-C would be welcome.

Summary

The M90 provides enhanced sound quality and a completely natural user experience.  With AutoSense, most users will find no need to switch programs at all. The smaller size, lighter weight, and ergonomic shape result in a more comfortable and secure fit.

Connectivity to any Bluetooth device is awesome! Hands-free phone calls and video conferencing provides crystal-clear sound on both ends of the conversation.

Pros:

• Smaller, lighter, more ergonomic
• Much better battery life
• AutoSense automatically adjusts program settings for all listening environments
• Improved sound quality – clarity and brightness, more environmental sounds
• Full Bluetooth connectivity to any device
• Hands-free calling and teleconferencing

Cons:

• Each processor must be assigned to one ear
• The battery charger can hold only three batteries
• Mini-USB and Micro-USB connectors on the charger and dryer.  Stiff cables.
